High Temperature Oil

High Temperature Oil | Chaintop XL Chain Lubricant

Fully synthetic oil for industrial chains and sliding guides.
Recommended for chain applications operating between 250 and 300 °C.
Formulated to limit carbon deposits under the recommended operating conditions.
Thermal stability and anti-wear performance for demanding heated processes.
Two grades documented: XL: 270 cSt and XL 100: 100 cSt, measured at 40 °C.

High Temperature Oil

High Temperature Conveyor Chain Oil

High Temperature Oil is a fully synthetic chain lubricant developed for industrial mechanisms exposed to elevated temperatures. Based on the Chaintop XL product range, it is intended for transport and drive chains, oven chains, drying tunnels and other applications operating between 250 and 300 °C.

Its formulation is designed to maintain effective lubrication while limiting carbon residue formation within the recommended temperature range. This helps keep chain mechanisms cleaner and supports reliable movement where lubricant deposits can interfere with operation. Supported chain designs include roller, leaf, Galle, bushing and inverted-tooth chains, together with sliding and plain guides.

High Temperature Oil

The datasheet lists two grades, XL and XL 100, with different viscosity and physical-property values. Grade selection should follow the equipment manufacturer’s lubrication requirements. Relubrication must be adjusted to the actual application temperature to maintain a suitable lubricating film. Use below 250 °C may cause deposits; applications above 300 °C fall outside the stated recommendation.

Key Features oven chain oil

Fully Synthetic Formulation

Developed specifically for chains and related mechanisms exposed to high operating temperatures.

Defined High-Temperature Application Range

Recommended for chain service between 250 and 300 °C. The operating conditions must be matched to this range when selecting the lubricant.

Reduced Carbon Residue Formation

Designed to minimize carbon buildup when used correctly, helping maintain cleaner chains and reducing deposit-related interference with chain movement.

Thermal Stability and Wear Protection

Combines high-temperature lubrication performance with anti-wear properties. The datasheet includes four-ball wear results for each grade.

Multiple Chain and Guide Applications

Suitable for the chain types and guide mechanisms listed in the datasheet, including roller, leaf, Galle, bushing and inverted-tooth chains.

Two Distinct Viscosity Options

XL has a viscosity of 270 CSt at 40 °C; XL 100 has a viscosity of 100 CSt at 40 °C. These are separate grades and should be selected according to equipment requirements.

Configurations / Grades

XL: Higher-viscosity option in this datasheet, with 270 cSt at 40 °C and 28 cSt at 100 °C.

XL 100: Lower-viscosity option in this datasheet, with 100 cSt at 40 °C and 14 cSt at 100 °C.

Applications high temperature conveyor chain oil

Industrial transport and drive chains.
Control and lifting chains.
Chains in painting equipment.
Drying tunnels and industrial ovens.
Textile stenter frames.
Roller, leaf, Galle, bushing and inverted-tooth chains.
Sliding and plain guides where the equipment lubrication requirements are met.

Production Advantages Industrial Chain Lubricant

Cleaner chain mechanisms: Reduced carbon buildup helps limit deposit-related operating problems.

Maintenance support: Cleaner lubrication can reduce the maintenance burden associated with accumulated residues.

Wear protection: Anti-wear properties support lubrication of moving chain components.

Potential energy benefit: Limiting deposits that obstruct chain movement can help avoid the associated increase in energy consumption; no quantified saving is claimed.

Technical Data

Property	XL	XL 100
Oil type	Fully synthetic	Fully synthetic
Appearance	Clear, transparent	Clear, transparent
Recommended application temperature	250–300 °C	250–300 °C
Density at 20 °C, gr/ml	0.935	0.971
Viscosity at 40 °C, cSt	270	100
Viscosity at 100 °C, cSt	28	14
Flash point, °C	256	232
Pour point, °C	-33	-20
Viscosity index	143	138
Four-ball wear test: wear scar diameter, 1 h / 40 kg	0.34	0.32
Copper corrosion rating	1a	1a
