WSD 121 – 120 W
120W single-channel soldering station with WP 120 soldering iron (with XT B soldering tip) and safety rest KH 18 (with WDC2 dry cleaner)
Description
WSD 121
| Technical Data | |
 |
This station is ESD safe. |
| Dimensions L x W x H: | 156 x 115 x 101 mm (6,53 x 4,52 3,97 inch) |
| Weight: | approx. 2,6 kg |
| Channels: | 1 |
| Power supply: | 230 V, 50/60 Hz |
| Power consumption: | 150 W |
| Protection class: | I |
| Temperature range: | adjustable 50°C – 450°C (150°F – 999°F) Adjustable temperature range varies among tools. |
| Temperature accuracy: | /- 9°C ( 48,2 °F / – 18,5°F) |
| Temperature stability: | /- 5°C ( 41 °F / – 23°F) |
| Equipotential bonding: | Via 3,5 mm pawl socket on back of device (normal state hard grounded) |
| Display: | LED |
| Bleeder voltage | Soldering tip (tip-to-ground) equal to IPC-J-001 |
| compatible tips: | XT-Serie |
Additional information
| Brand |
Weller |
|---|
